Item # 1214

1/4″ Dr. Slim Head Ratchet Wrench

• Slim head design allows for access to hard to reach areas
• Ideal for body shops and repair shops to work in areas such as under-dashboard and confined space engine repairs
• Working torque range from 5 to 20ft./lbs.
• “Precision Forged” ratchet yoke made of Cr-Mo alloy steel with optimized heat treatment to maintain peak performance and prevent “Spreading” which makes other air ratchets lose power
• Precision machined anvil ensures that ratchet pawl and yoke can properly engage with each other at any position

OFF SHELF (Try Related Products Below)

Part Breakdown

Download(1 MB)

Product Info

Download(230 KB)

SPECIFICATIONS:
Square Drive: 1/4"
Free Speed: 240rpm
Overall Length: 6-1/2" (165mm)
Net Weight: 1.1 lbs. (0.5kg)
Working Torque Range: 5-20ft./lbs
Max. Torque: 30ft./lbs.
Bolt Capacity: 3/8" (10mm)
Air Inlet Thread NPT: 1/4"
Air Hose I.D. Size: 1/4" (6mm)
Avg. Air Consumption: 2.5cfm
Air Pressure: 90psi
