Item # 3072
Nitrogen Wall Mounted Inflator
• Die cast aluminum housing
• Vandal resistant mechanical switches provide longer unit life
• Ceramic sensor provides highly accurate readings that are clear and easy to read
• Accurate to within 0.02BAR (0.3PSI)
• Ideal for Automobile Dealerships, Truck Service Centers and all Service
Centers currently inflating with Nitrogen
• Purge function for Nitrogen inflation
Specifications::
Inflation Range: 0.5-10bar (1000kpa/145psi/10kg/cm2)
Accuracy: +/-0.02bar (+/-0.3psi)
Max Inlet Air Supply: 10.5bar (150psi)
Nitrogen flow: 105.944CFM
Supply voltage: AC 110~240V (50~60Hz)
Watt: 12W Max.
Working Temperature: -10_~50_ (14_~122_)
Relative Humidity: up to 95% RH non-condensing
