Item # 605ST

ONYX Straight Type Punch/ Flange Tool with 5.5mm Punch

• Punch designed for easy replacement
• Performs hole punching and panel crimping
• Features a rotating head for convenient use
• Every pull of the lever delivers a single punch or a single
flange crimp with precision control
• Forms an offset crimped edge on sheet metals for no-bump lap welds
• Lightweight
• Durable construction
• Reduces metal fabrication time in half

Punch Diameter: 5.5mm (7/32")
Punch Capacity: 1.6mm (1/16")
Crimping Capacity: 1.6mm (1/16")
Piston Stroke: 5/32" (4mm)
Overall Length: 9.84" (250mm)
Net Weight: 2.6lbs. (1.18kg)
Air Inlet Thread NPT: 1/4"
Air Hose I.D. Size: 3/8" (10mm)
Avg. Air Consumption: 4cfm
Air Pressure: 90-120psi
